1.9inch MCU Medical TFT LCD Module 4-SPI 170*320 IPS LCD Display Screen

Display model GL190RAN30A is a transmissive type color active matrix LCD screen with capacitance touchscreen thin-film transistor(TFT)liquid crystal display(LCD)that uses amorphous silicon TFT as a switching device. This Module is a TFT LCD module, a driver circuit, and a backlight unit. It has a 1.9 inch diagonally measured active display area with (170horizontal by 320 vertical pixels)resolution and can display up t0 262K colors.

Additional information

Item No.

GL190RAN30A

MOQ

2pcs

Lead Time

7 Working Days For Samples.

Payment Term

Paypal, T/T

Status

Mass Production

Availability

5 Years Stable Supply

Customization

Support

Product Details



Display model GL190RAN30A is a transmissive type color active matrix LCD screen with capacitance touchscreen thin-film transistor(TFT)liquid crystal display(LCD)that uses amorphous silicon TFT as a switching device. This Module is a TFT LCD module, a driver circuit, and a backlight unit. It has a 1.9 inch diagonally measured active display area with (170horizontal by 320 vertical pixels)resolution and can display up t0 262K colors.



  • Product Features:
[table “” not found /]

  • Product Application:
  1. Smartwatch.
  2. Wearable devices
  3. handheld device
  4. POS
  5. Smart camera
  6. Intelligent education robot
  7. Kids toys
  8. Smart home controller
  9. Advanced driver-assistance systems (ADAS)
